High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components

Name: HighSpeed CNC Turned Graphite Electrode with 00020005mm Tolerance and ISO9001 Certified Precision Machined Components
Brand: IMission
Price: 0.1 USD

Quality High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components for sale

Brand Name : IMission

Model Number : CNC Turning

Certification : ISO9001

Place of Origin : China

MOQ : I PC

Price : 0.1~5USD

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 10000pcs per month

Delivery Time : 7~35 working days

Packaging Details : Bubble and Carton or Customization

Material : Aluminum

Weight : 0.1-8kg

Service : OEM or ODM

Key Word : CNC Turning Parts

Shipping Method : Express, Air, Sea, Etc.

Product Process : CNC Turning

Quality : 100% Inspection

Our Service : 24 Hours Online

Feature : Durable And High Precision

Surface Finishing : Anodizing, Plating, Polishing, Etc

Processing : CNC Machining, CNC Milling, CNC Turning,Stamping...

Drawing : IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad,PDF or Samples

Highlight : ISO9001 Certified CNC Milling Parts，100% Inspection CNC Machined Parts

Contact Now

High-Speed CNC Turned Graphite Electrode

CNC Turning Parts Specifications

Product Name	CNC Turning Parts
Material Available	Aluminum
Processing	CNC Turning
Tolerance	±0.002~0.005mm
Drawing Accepted	IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad, or Samples
Inspection	CMM, Projector, Height Gauge, etc.
Lead Time	7~35 working days
Quality Assurance	ISO9001:2015, SGS, RoHs
Payment Term	MoneyGram, Western Union, T/T, D/P, D/A, L/C
Price	According to your drawing or requirements

Packaging and Delivery

Packaging	Bubble and Carton or Customization
Port	Shenzhen

High-Speed CNC Turned Graphite Electrode with ±0.002~0.005mm Tolerance and ISO9001 Certified Precision Machined Components

CNC Turning Parts Characteristics

CNC turning parts feature high precision and excellent consistency, and are capable of machining metal or non-metal components with diverse complex structures such as shafts and discs. Controlled precisely by pre-set programs, the machining process enables one-time forming of intricate details like complex threads, chamfers and grooves, making these parts well-suited for the stringent application requirements in machinery manufacturing, automotive, aerospace and other industries.

Secondary Operations & Finishing

Value-Added Services

Operation	Equipment Used	Capability/Specification
CNC Milling	3/4/5-axis mills	Cross-holes, flats, keyways, complex features
Drilling/Tapping	CNC drill units	Deep hole (up to 10× diameter), micro-drilling (Ø0.3mm+)
Grinding	Cylindrical grinders	ID/OD grinding, surface grinding
Heat Treatment	Vacuum furnaces	Hardening, tempering, stress relieving, annealing
Welding	TIG, laser welders	Precision welding for assemblies
Assembly	Cleanroom facilities	Press fits, adhesive bonding, mechanical fastening

Surface Finishes

Finish Type	Process	Typical Ra Value	Characteristics
As-Machined	CNC turned	0.8-3.2μm	Cost-effective, tool marks visible
Polished	Mechanical polishing	0.1-0.4μm	Reflective, smooth, cosmetic quality
Anodized	Type II/III anodizing	0.4-1.6μm	Decorative, corrosion resistant (Al)
Plated	Electroplating	Varies	Chrome, nickel, zinc, tin coatings
Passivated	Chemical treatment	Base material finish	Corrosion resistance (stainless)
Painted/Powder Coated	Spray application	Varies	Color options, additional protection
Black Oxide	Chemical conversion	Base material finish	Mild corrosion resistance, appearance

Quality Assurance & Inspection

Inspection Equipment

Multi-Sensor CMMs: 3D measurement with 0.001mm accuracy
Optical Comparators: Profile projection with 20× to 100× magnification
Surface Roughness Testers: Portable and benchtop Ra/Rz measurement
Hardness Testers: Rockwell, Brinell, Vickers, and micro-hardness
Thread Gauges: Complete sets to ISO/ANSI standards
Digital Calipers/Micrometers: 0.001mm resolution, calibrated regularly
Roundness Testers: Concentricity and cylindricity measurement
Force Measurement: Torque testing, spring constant verification

Quality Certifications & Processes

ISO 9001:2015 certified quality management system
First Article Inspection (FAIR): AS9102/PPAP documentation available
Statistical Process Control (SPC): Real-time monitoring of critical dimensions
Material Traceability: Mill test certificates, heat/lot number tracking
Calibration Program: All inspection equipment calibrated to NIST standards
Document Control: Revision-controlled drawings and specifications

Customization & Service Workflow

Design Support Services

DFM Analysis: Design for manufacturability review within 24 hours of drawing submission

Engineering Collaboration: Co-development with customer engineering teams

Rapid Prototyping: 3D printing (SLA, SLS, MJF) available for concept validation

Order Process

Quotation Request: Submit drawings (DXF, DWG, PDF) or 3D models (STEP, IGES, SLDPRT)

Technical Review: Engineering assessment of materials, tolerances, and finishing

Commercial Proposal: Detailed quotation including unit pricing, tooling costs, lead time

Prototype Approval: Sample production with inspection report submission

Production Release: Scheduled manufacturing with milestone updates

Quality Verification: Final inspection report prior to shipping

Delivery & Support: Tracking information and post-sales technical assistance

Competitive Advantages

Technical Expertise

12+ years average experience among engineering staff

Dedicated project management for each account

Continuous process optimization through Six Sigma methodologies

Supply Chain Reliability

Long-term partnerships with certified material suppliers

Risk mitigation through multi-source material procurement

Inventory management programs for repeat components

Global Compliance

ISO 9001:2015 certified quality management system

Conflict-free mineral sourcing documentation

REACH and RoHS compliance for applicable materials
